Lead Ores:
The most common mineral of lead, is primarily lead sulfide (PbS). The sulfide is oxidized to a sulfite (PbSO3) which thermally decomposes into lead oxide and sulfur dioxide gas. (PbO and SO2) The sulfur dioxide (like the carbon dioxide in the example above) is expelled, and the lead oxide is reduced. Anglesite, Cerussite, Pyromorphite, Mimetite and Wulfenite are other lead ores. Other elements frequently present with lead ores include zinc and silver.
Lead Smelting:
Lead is usually smelted in a blast furnace, using the lead sinter produced in the sintering process and coke to provide the heat source. As melting occurs, several layers form in the furnace. A combination of molten lead and slag sinks to the bottom of the furnace, with a layer of the lightest elements referred to as speiss, including arsenic and antimony floating to the top of the molten material. The crude bullion and lead slag layers flow out of the 'furnace front' and into the 'forehearth', where the two streams are separated. The lead slag stream, containing most of the 'fluxing' elements added to the sintering machine (predominantly silica, limestone, iron and zinc) can either be discarded or further processed to recover the contained zinc.
The crude lead bullion, containing significant quantities of copper will then undergo 'copper drossing'. In this step elemental sulphur, usually in solid form is added to the molten crude lead bullion to react with the contained copper. A "matte" layer forms in this step, containing most of the copper originating from the crude lead bullion and some
